序号 NO 设备名称 Equipment name 型号 Model 实验名称 Experiment name 实验目的 Experiment purpose 设备图片 Equipment picture 1 箱式紫外线 老化试验箱 Ultraviolet aging test chamber UVA-1300 UV实验 Ultraviolet aging experiment 模拟阳光,雨水和露水,加速评价产品耐候性 Simulate sunlight, rain, and dew to speed up evaluation of product weather resistance 2 两厢式冷热冲击试验机 Two-Compartment Thermal Thock Testing Machine HTS-50-150-150L 温度冲击实验 Temperature shock experiment 模拟高低温间循环转换,评价产品耐环境工况 Simulate the conversion between low temperature and high temperature to evaluate the product's environmental resistance 3 可程式恒温恒湿 试验箱 Programmable constant temperature and humidity test chamber HCT-50-150-800BT 1,温度循环实验 Temperature cycling experiment 2,高温工作实验 High temperature working experiment 3,低温工作实验 Low temperature working experiment 4,交变湿热实验 Alternating Damp Heat Experiment 模拟低温或高温高湿环境,评价产品耐环境工况 Simulate low temperature or high temperature high humidity environments to evaluate product environmental resistance 4 换气式老化 试验机 Ventilation aging testing machine XL-016A 护套热老化试验 thermal aging test 护套高温抗开裂实验High temperature anti cracking test of sheath 模拟高温环境,加速评价非金属材料耐老化工况 Simulate high temperature environment to accelerate the evaluation of non-metallic material aging resistance 5 插拔寿命及温升 试验机 Plug and pull life and temperature rise tester HH-CMWS1000A 内部温升实验 Internal temperature rise experiment 插拔寿命实验 Plug and unplug life test 3,插拔力试验 Insertion and extraction force test 成品插拔力,插拔寿命,温升试验 Finished product plug-in force, plug-in life, temperature rise test 6 可程式恒温恒湿 试验机 Programmable constant temperature and humidity testing machine XL-WS150 护套低温卷绕实验 Sheath low temperature winding experiment 低温卷绕实验的主要目的是评估线缆材料在低温环境下的抗开裂性能,以确保线缆在低温条件下的安全性和可靠性. The main purpose of the low-temperature winding experiment is to evaluate the anti cracking performance of cable materials in low-temperature environments, in order to ensure the safety and reliability of cables under low-temperature conditions. 7 万能拉力试验机 Universal tensile testing machine HH-1000D 端子拉力实验 Terminal tension test 拉力,抗张强度等机械性能测试 Mechanical properties testing such as tension and tensile strength 8 盐雾试验机 Salt spray tester HH-60 盐雾实验 Salt spray test 电子配件盐雾腐蚀试验 Electronic parts salt spray corrosion test 9 电缆弯曲 试验机 Cable bending testing machine HH-WQ01 电缆接口弯曲摇摆试验 Cable interface bending and swing test 确定样品在使用过程中,线缆样品经过反复弯曲摇摆,不会引起线缆折断 Make sure that the sample in the use of the process, the cable sample after repeated bending swing, will not cause cable break 10 双臂跌落试验机 Double-arm drop tester HH-8515 模拟产品包装跌落测试 Simulated product packaging drop test 考核包装件在实际运输,装卸过程中受到跌落冲击的影响程度,评定包装件在搬运过程中耐冲击强度和包装设计的合理性. To assess the impact of the drop impact on the packaging during the actual transportation and loading and unloading, and to evaluate the impact strength of the packaging during the handling and the rationality of the packaging design. 11 膜厚测试仪 Film thickness tester XRF-2020L 镀层膜厚测试实验 Coating film thickness testing experiment 测量金属镀层厚度,同时可对电镀液进行分析. Measure the thickness of metal coating and analyze the plating solution at the same time. 12 全自动 线束分析仪 Automatic wire harness analyzer MicroX 45 端子截面分析测试 Terminal section analysis and testing 线束端子压接截面分析 Wire harness terminal crimping cross-section analysis 13 IPX7浸水试验机 IPX7 immersion testing machine HH-IPX7 防水试验 Waterproof test 评估试验样品的防水性能 Evaluate the waterproof performance of the test sample 14 电线单根垂直 燃烧试验仪 Single vertical wire Combustion tester YH-8820CB GB18380/IEC60332单根绝缘电线电缆火焰垂直蔓延试验 GB18380/IEC60332 single insulated wire and cable vertical flame spread test 主要针对导体直径大于8mm(截面积大于0.5mm2))的单根电线电缆的可燃性能进行评定 Mainly aimed at evaluating the flammability of single wires and cables with a conductor diameter greater than 8mm (cross-sectional area greater than 0.5mm2) 15 标准电线电缆和软线燃烧试验机 Standard wire and cable and flexible wire combustion testing machine XL-535UL 电线电缆和软线VW-1垂直燃烧试验 VW-1 vertical combustion test for wires, cables, and flexible cords 评定电线电缆或软线阻燃性能和着火时向附近的可燃性物质传播火焰的能力. Assess the flame retardancy of wires, cables, or flexible cords and their ability to spread flames to nearby flammable substances during ignition. 16 氧指数测定仪 Oxygen index meter XLYZ-75 材料氧指数测定 Material Oxygen Index determination 测定材料氧指数,评定材料的阻燃性能 The oxygen index was measured to evaluate the flame retardancy 17 端子拉力试验机 Terminal tensile testing machine YH­8812BNG 端子拉力实验 Terminal tension test 线束端子压接拉力测试 Wire Harness Terminal Crimping Tensile Test 18 电脑全自动插拔力试验机 Computer automatic insertion and extraction force testing machine HH-1000D 端子插拔实验 Terminal insertion and extraction experiment 端子插拔力,插拔寿命测试 Sub-plug-in force, plug-in life test 19 纸箱抗压强度试验机 Carton compressive strength testing machine PNSI-800 瓦楞纸箱等包材耐压,形变,堆码试验 Compression, deformation, and stacking tests for packaging materials such as corrugated boxes 评价纸箱耐压,形变,堆码强度 Evaluate the pressure resistance, deformation, and stacking strength of cardboard boxes 20 纸箱耐破度试验机 Carton burst testing machine PNSI-02 纸箱耐破试验 Carton burst test 测定各种纸板及单层和多层瓦楞纸板的耐破强度 Determination of burst strength of various types of cardboard and single-layer and multi-layer corrugated cardboard 21 网络分析仪 network analyzer CTS-650 电缆通信性能测试 Communication cable communication performance testing 通信电缆传输特性元件级测试 Communication cable transmission characteristics component level test 22 数字式投影仪 Digital projector JT12A-B 线缆外径厚度测试 Measurement of cable outer diameter and thickness 投影式电缆结构尺寸厚度测量 Projection type cable structure dimension thickness measurement 23 线缆拉力试验机 Cable tensile testing machine BLD-1026 材料机械性能试验 mechanical performance test 拉力,抗张强度等机械性能测试 Mechanical properties testing such as tension and tensile strength 24 电子拉力试验机 Electronic tensile testing machine XL-TST-5 护套机械性能试验 Sheath mechanical performance test 评价护套材料的机械性能(抗张强度,伸长率) Evaluate the mechanical properties of sheath materials (tensile strength, elongation) 25 数字直流电桥 Digital DC bridge QJ-84A 电阻,电阻率测量 Resistance, resistivity measurement 测试铜杆等材料的电阻及电阻率 Test the resistance and resistivity of materials such as copper rods 26 显微镜 microscope KYM-300 绝缘等切片观测 Insulation slice observation 电缆结构单元显微测量分析 Cable structure unit microscopic measurement and analysis 27 高压测试仪 High voltage tester ACT-8103 1,绝缘电阻测试 Insulation resistance test 2,耐电压测试 Voltage withstand test 用于测试样品的绝缘电阻大小和耐电压性能 Used to test the insulation resistance and voltage resistance performance of the sample 28 耐电压测试仪 Withstanding Voltage Testers CC-2670A 耐电压测试 Voltage withstand test 用于测试线缆的耐电压性能 Used to test the voltage resistance performance of cables 29 绝缘电阻测量仪 Insulation resistance measuring instrument PC-40B 绝缘电阻测试 Insulation resistance test 用于测试线缆的绝缘电阻 Used to test the insulation resistance of cables 30 福禄克分析仪 Fluke analyzer DSX2-8000CH 电缆通信性能测试 Communication cable communication performance testing 通信电缆传输特性链路级测试 Communication cable transmission characteristics link level test

Customize boxes of different sizes for the products. Some reference materials are as follows: The large hole is 7 centimeters. The small hole is 3 centimeters.        Palletized Packaging: Each order has its own container loading diagram. Some examples are as follows:
