| Brand Name: | ITI-LINK |
| Model Number: | ITI-CT5F-026 |
| MOQ: | 1000pcs |
| Price: | $50-$100 |
| Delivery Time: | 15-45Days |
| Payment Terms: | T/T |
| Construction Item Description | Electrical Property |
|---|---|
| Conductor Material: Bare Solid Copper (elongation: 19 ~ 24%) OD: 24 AWG |
Conductor Resistance at 20°C: ≤ 9.5 Ω / 100m Resistance unbalance within a pair: ≤ 2% |
| Insulation Material: HDPE 8303 OD: 0.90 ± 0.01 mm Average THK: 0.20 mm Color: 1p: white + 2 blue stripes & blue, 2p: white + 2 orange stripes & orange, 3p: white + 2 green stripes & green, 4p: white + 2 brown stripes & brown |
Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V: >1500 MΩ / 100m Mutual capacitance: 5600 pF / 100m MAX Capacitance unbalance pair to ground at 800Hz or 1 kHz: ≤ 160 pF / 100m |
| Pair Twist Lay & Direction: 1p: S=20.0 mm (28%), 2p: S=17.5 mm (24%), 3p: S=22.0 mm (32%), 4p: S=15.5 mm (21%) |
Characteristic impedance at 100MHz: 100 ± 15 Ω Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min - No breakdown |
| Mechanical Property Insulation elongation before aging: ≥ 300% tensile strength before aging: ≥12 MPa elongation after aging: ≥ 150 % tensile strength after aging: ≥10.5 MPa |
Jacket elongation before aging: ≥ 125 % tensile strength before aging: ≥ 12 MPa elongation after aging: ≥ 100 % tensile strength after aging: ≥ 100 MPa |
| Inner Assemble Lay: S=90 ± 5 mm Direction: according to the drawing Filler: Ripcord 300D Drain Wire: Tinned Copper |
Packing Drum: NA Master Carton: NA |
| Outside Shield Construction: / Material: Polyester/Aluminium (PET/ALU) Coverage: ≥ 115% |
|
| Jacket Material: LSZH, 60P, -20~75℃ Hardness: 81 ± 3 OD: 5.2 ± 0.15 Average THK: 0.45 ~ 0.55 Color: Grey Marking Color: black Marking: according to the customer's requirements |
